QJMOTOR SRV 600 V
The QJMOTOR SRV 600 V is a modern cruiser with a characteristic V4 engine and a low-slung seat. It combines a classic cruiser look with modern electronics, sporty performance, and a belt drive.
Engine and Performance
Engine type: Four-cylinder V4 at a 90° angle
Stroke cycle: 4-stroke
Valves: 16 valves, DOHC
Cooling: Liquid cooling
Displacement: 600 cm³
Bore × stroke: 61.0 × 48.0 mm
Compression: 11.5:1
Maximum power: 69.4 HP at 10,500 rpm
Maximum torque: 53 Nm at 8,500 rpm
Fuel system: Electronic injection EFI
Lubrication: Wet sump
Clutch: Wet, multi-plate
Transmission: 6-speed
Final drive: Belt
Final drive ratio: 3.040
Starting: Electric
Average consumption: 4.8 L/100 km according to WMTC3
Maximum speed: Approximately 180 km/h
Fuel tank: 16 L
Suspension, Brakes, and Wheels
Front suspension: Marzocchi USD fork
Fork diameter: 41 mm
Front suspension travel: 120 mm
Front suspension adjustment: Compression and rebound
Rear suspension: Twin shock absorbers
Rear adjustment: Spring preload
Front brakes: Dual 300 mm discs
Front calipers: Radial with four pistons
Rear brake: 260 mm disc
Rear caliper: Single-piston
ABS: Dual-channel
Traction control: TCS with switch-off capability
Front tire: 130/90-16
Rear tire: 180/65-16
Dimensions and Weight
Length × width × height: 2,280 × 830 × 1,115 mm
Wheelbase: 1,580 mm
Ground clearance: 140 mm
Seat height: 720 mm
Weight with fluids: 228 kg
Rake: 28°
Factory Equipment
Full LED lighting
Circular TFT screen
TPMS tire pressure and temperature monitoring system
Bluetooth and Wi-Fi connectivity
Turn-by-turn navigation
Phone call notifications
Dual USB port – Type-A and Type-C
Bar-end mirrors
Custom seat with a height of 720 mm
TCS kill switch
Dual side-mounted exhaust systems
