Engine | |
Type: | 1 cylinder, 4 stroke, air cooled |
Displacement: | 124cm3 |
| Bore x Stroke: | 54 mm x 54 mm |
Compression ratio: | 9.0 ± 0.1 : 1 |
Max. power (kw/r/min): | 5.5 kw / 7500r/min |
Max. Torque (n.m/r/min): | 8.6 N.m / 5500r/min |
Clutch type: | Manual clutch |
Ignition: | C.D.I |
Starting system: | Electric/kick |
Transmission system: | Chain drive |
Chassis | |
Braking system (front / rear): | Drum/drum |
Max. speed (km/h): | ≥85 |
Tire (front / rear): | 2.50-17 / 2.75-17 |
Fuel tank capacity (L): | 9 |
Fuel consumption (L/100km): | ≤2.1L |
Dimensions | |
LxWxH (mm): | 1900mmx760mm x1110mm |
Seat height (mm): | 755 |
Wheelbase (mm): | 1210 |
Ground clearance (mm): | 140 |
Max. load capacity (kg): | 150 |
Dry weight (kg): | 86 |
Container loading | |
Packing size (mm): | 1560mm×330mm×820mm |
Optional items | |
| Engine displacement: | 125cc |
Specifications
| Available colors | Blue, Red, Black |
|---|---|
| Available colors | Red , Black , Blue |
