The air conditioner package includes complete mounting equipment worth 3000 denars:
- Complete 3-meter copper pipes
- Connection cable for indoor and outdoor units
- Bandage tape
- 1.5 meter condensate hose
General Specifications
| Product Code | ASW-H24B4/FCR1-RU |
| Power Supply | 220-240V~/50Hz |
| Refrigerant Type | R410a |
| Refrigerant Quantity | 0.54 kg |
| Waterproof Class | IPX4 |
| Outdoor Unit Weight | 44 kg |
| Indoor Unit Weight | 11.5 kg |
Heating and Cooling Specifications
| Nominal Cooling Capacity | 7.10 kW |
| Nominal Heating Capacity | 7.30 kW |
| Maximum Cooling Capacity | |
| Maximum Heating Capacity | |
| Nominal Cooling Current | 9.83 A |
| Nominal Heating Current | 8.98 A |
| Maximum Cooling Consumption | 2.21 kW |
| Maximum Heating Consumption | 2.02 kW |
Other Specifications
| Maximum Input Current | 16 A |
| Maximum Input Power | 3.15 kW |
| Maximum Discharge Pressure | 4.15 MPa |
| Maximum Suction Pressure | 1.15 MPa |
| Air Flow Volume | 970 m3/h |
| Maximum Indoor Unit Noise Level | 43 dB |
| Maximum Outdoor Unit Noise Level | 56 dB |
Specifications
| Brand | AUX |
|---|---|
| Cooling | Capacity:7,300 W, Nominal Input Current:2,267 W, Nominal Current Value:9.8A |
| Heating | Capacity:7,400 W, Nominal Input Current:2,049 W, Nominal Current Value:8.9A |
| SEER/SCOP | 6.1/4.0 W/W |
| UPC | 15126 |
| Cooling | Capacity:7,300 W , Nominal Input Current:2,267 W , Nominal Current Value:9.8A |
| Heating | Capacity:7,400 W , Nominal Input Current:2,049 W , Nominal Current Value:8.9A |
