The air conditioner package includes complete installation equipment worth 3000 denars:
- Complete copper pipes, 3 meters long
- Bandage tape and elbows
- Condensation hose, 1.5 meters long
General Specifications
| Product Code | ASF-H24A4/AHAR1DI-EU |
| Power Supply | 220-240V~/50Hz |
| Refrigerant Type | R32 |
| Refrigerant Quantity | 1.8 kg |
| Waterproof Class | IPX4 |
| Outdoor Unit Weight | 53 kg |
| Indoor Unit Weight | 34 kg |
Heating and Cooling Specifications
| Rated Cooling Capacity | 7.4 kW |
| Rated Heating Capacity | 9.5 kW |
| Maximum Cooling Capacity | |
| Maximum Heating Capacity | |
| Rated Cooling Current | 10.3 A |
| Rated Heating Current | 13.2 A |
| Maximum Cooling Power Consumption | 2.28 kW |
| Maximum Heating Power Consumption | 2.68 kW |
Other Specifications
| Maximum Input Current | 12.0 A |
| Maximum Input Power | 2.90 kW |
| Maximum Discharge Pressure | 4.15 MPa |
| Maximum Suction Pressure | 1.15 MPa |
| Airflow Volume | 1200 m3/h |
| Maximum Indoor Unit Noise Level | 47 dB |
| Maximum Outdoor Unit Noise Level | 56 dB |
